ON-SITE SODIUM HYPOCHLORITE GENERATORS
(continuous generator series)
Illustrative pictures
Since 1996 Hidrogeron has been developing, manufacturing and supplying On-site Sodium Hypochlorite Generators (OSHG) to municipalities and industries in a broad range of sizes. Adopting on-site electrochlorination is an increasing trend worldwide with Hidrogeron being one of the forerunners with over 10,000 systems installed.
Based on the electrolytic process, OSHG systems only require sodium chloride (salt), water, and electricity to produce 0.8% sodium hypochlorite on-site at your plant. NSF grade solar salt is readily available, inexpensive and non-hazardous to transport or handle. The low concentration hypochlorite solution produced safely addresses all labor and environmental concerns. The solution is not classified as a hazardous chemical.
• Skid mounted.
• External brine saturator.
• External Hypochlorite dosing.
• Integrated water dilution and brine dosing system.
• HMI/PLC monitoring and control locally or remotely
• External hypochlorite storage with hydrogen venting system.
• Designed for rugged environment.
SMART CHLORINATION
Reduces pre and
post-chlorination
by up to
18% and 30% respectively
Labor and
environmental
liability
Reduces operational cost
with cheap and
accessible raw material
Steady level of
residual to the
end of
the distribution system
Higher oxidant potential
compared to other
chlorination
methods
Easily integrate with
chlorine analyzers, dosing
and
control system
5 YEARS WARRANTY
The electrolytic cell, wich is the most important part of the system, is exclusively machined and manufactured in-house for tight quality control, under ISO9001.
For this reason, we are safe to offer our customers a 5-year warranty against manufacturing defects and premature wear of the electrode set.
SEGMENTS WE SERVE
SANITATION
INDUSTRIAL
SWIMMING POOLS
HG SKID SERIES MODELS
| MODEL | PRODUCTION kg - active chlorine per day | SALT kg / day | ENERGY kw / day |
|---|---|---|---|
| HG 3000 | 3 | 13,5 | 13,5 |
| HG PLUS 6 | 6 | 27 | 27 |
| HG PLUS 12 | 12 | 54 | 54 |
| HG PLUS 24 | 24 | 108 | 108 |
| HG PLUS 36 | 36 | 162 | 162 |
Equipment and models subject to change without notice
HG SKID SERIES MODELS
| MODEL | PRODUCTION kg - active chlorine per day | SALT kg / day | ENERG kw / day |
|---|---|---|---|
| HG PLUS 70 | 70 | 315 | 315 |
| HG PLUS 100 | 100 | 450 | 450 |
| HG PLUS 150 | 150 | 675 | 675 |
| HG PLUS 200 | 200 | 900 | 900 |
| HG PLUS 250 | 250 | 1125 | 1125 |
Equipment and models subject to change without notice
Industrial processes
Water treatment station
Oil platforms
Well Chlorination
Chiller
Frozen
Iron Oxidation
Industrial Effluents
Ammonia oxidation
Sewage treatment station
Wells
Open swimming pools
Thermal pools
Resorts
Water parks
Wave Pools
Water mirrors
Waterfalls
Water toys
Electric Power: 220 | 380 | 440V.
Salt consumption: 4.5 Kg / Kg of active chlorine produced.
Energy Consumption: 4.5 KW / kg of chlorine produced.
Meets any treatment flow.
Water
Energy
Cooking salt
